It can be easily mounted from both sides of the car. Quick connection to the roof bar and "T-slot" adapters included. With the 360° rotating vice it is possible to fix
the frame at several points. The friction closing system makes this product particularly suitable for carbon frames. Bike support arm equipped with adjustable brake to facilitate hooking during loading. Bike racks from 12" to 29", frames from 22 to 50 mm. Complete with lockable bike/bike rack and bike/roof rack. Bike transport up to 20kg.

Data sheet
max number of bikes 1
Aluminum material
color Black Anthracite
total maximum load (kg) 20
type of bike assembly Frame and wheel
max dimensions bike frame section (cm) from 2 to 5
bike size (inches) from 12" to 29''
max bike wheel width (cm) 7
max wheelbase bike (cm) 125
fixing with bike-carrier key YES
fixing with bike-car key YES
product weight (kg) 4.7
tested according to ISO 11154:2006, Tuv-GS
city crash test YES
e-bikes YES
suitable for SI carbon frame
max roof bar dimensions (cm) 8 (with accessory kit for fixing to the frame)
availability of "t"-slot adapters Included
accessory applicability for NA through axle
packaging type Box
bike rack dimensions 30*143*11



barcode: 8015058007101
code: 710
