The SE-601 Series ECGs are cost-effective solutions that can be adapted to any workplace setting, including hospitals, routine checkups, and emergency cases.
6-channel ECG SE-601C 5.7" color LCD monitor with standard configuration:

Main Unit: Six ECG channels, 5.7" 640 x480 color LCD monitor, alphanumeric keyboard, internal speakers, 12 waveforms viewable simultaneously, Two-step exercise test with periodic recording 200 ECGs storable in internal memory, printout 110mm paper Z-fold rechargeable lithium battery, AC/DC mains cable and integrated thermal printer.

- Lightweight, portable and portable
Convenience of transport and use in environments with limited space
- Easy data entry and use
Alphanumeric keyboard and immediate operations with one touch
- Diet
Built-in rechargeable Li-ion battery, AC/DC power supply
- Pacemaker detection
The pacemaker detection function meets the requirements of ANSI/AAMI EC11 standards
- Display
Large backlit color screen (5.7" TFT LCD)
Accurate waveform display on large screen (5.7" STN LCD)
- Interpretation
For adult and pediatric patients
Automatic measurement and interpretation verified with the authoritative CSE database
- Periodic registration
Two-step exercise test with periodic logging
- Rhythm recording
Selectable single or triple derivation
- HRV analysis
Heart Rate Variability (HRV) analysis
- Waveform
12-lead ECG, complex print formats to meet different needs
- Registration
Internal thermal printer and external printer
- Data storage and transmission
200 ECGs in internal memory
Storage on external media: USB flash drive
Data transmission to PC via Ethernet or RS232 port
- PC based data management software
Smart ECG Viewer is the ideal solution for data management (optional)
- Back panel with 4 holes
Useful for fixing the ECG to plates/panels/walls/trolleys/etc...

Technical features:
Input Circuit: Built-in defibrillation protection
Lead: 12 standard leads
Acquisition mode: Simultaneous acquisition of 12 leads (10-24 s adjustable)
A/D converter: 24 bit
Sampling rate: 1,000 Hz/channel, 10,000 Hz for pacemaker detection
Input voltage range: ±5 mVpp
Time constant: > 3.2 s
Frequency response: 0.05 Hz - 150 Hz
Calibration voltage: 1 mV ± 2
Sensitivity: 2.5; 5; 10; 20; 10/5; AGC (mm/mV)
Input Impedance: >50M Ohm
Input circuit current: < 10 nA
Noise level: <12.5p Vpp
Patient leakage current: <10 pA(220V-240
Patient auxiliary current: < 0.1 p A (DC)
Filters:
EMG filter 25 Hz/35 Hz/45 Hz/OFF
Antiskid 0.05/0.15/0.25/0.5/0.32/0.67 Hz
Low-pass filter 75 Hz/100 Hz/150 Hz
AC Filter 50Hz/60Hz
CMRR: >115dB
Recording Mode: Automatic/Manual/Rhythmic
Rhythm lead: Selectable single or triple channel
Power: AC (100-240V at 50/60Hz)
12V car converter
Drums:
Built-in rechargeable lithium-ion battery
2200 mAh at 14.8 V for 6 hours of general use or continuous printing of 280 copies of ECG
Recorder: Thermal printer
Number of channels: 3, 4, 6
Printing: on paper 110 mm 140 mm 142 sheets ("Z" fold)
Recording speed: 5 mm/s, 6.25 mm/s, 10 mm/s, 12.5 mm/s, 25 mm/s, 50 mm/s (i 3)
Weight: About 3kg (with battery and paper)
Dimensions: 322 x 310 x101 mm
Screen: 5.7" TFT color LCD, 640,480 dots

Supplied:
1 4mm ECG cable with 4mm banana plugs
1 Set of 6 precordial suction cup electrodes for adults
1 Set 4 peripheral electrodes
1 x 20 m Z-fold paper pack (110 x 140 mm)
1 Power cord (European standard)
1 Rechargeable lithium battery (2200mAh)
1 Fuse (1A)
1 User manual in Italian



code: LTD445S
