Compact and light with foldable handle for transport and minimum bulk. 8.4" COLOR TOUCH SCREEN display for optimal viewing. Digital anti-skid base line filters, AC and EMG interference. Automatic Stand By mode for energy saving during use with the built-in rechargeable battery and for savings in time of using the LCD Super easy operation with one button capture/print.
Integrated Ethernet and USB with side access. Internal memory up to 200 patients with tracings and interpretations. Alphanumeric keyboard.

- Compact, lightweight design with carrying handle
- 8.4 high resolution screen
- USB port for patient data transmission
- RJ45 and RS-232 ports for data transmission to PC
- Rechargeable LI-ion battery included
- Single button
- Energy saving and LCD saving modes
- Various print formats
- Full digital filter
- Automatic detection and storage of arrhythmia
- Internal storage of up to 200 digital ECGs
- Auto measurement
- Accurate ECG interpretation with SEIMP program
- Analysis of the variation of the cardiac trend
- Optional Smart Ecg viewer software for PC measurement

Technical features:
Circuit: Defibrillator and pacemaker protection
Tracks: 12 standard - Acquisition mode: 12 simultaneous tracks
A/D converter: 12 bits
Signal input range: ± 5m Vpp
Time constant: > 3.2s
Frequency range: 0.05Hz-150Hz
Calibration voltage: 1mV ±2
Sensitivity: 2.5, 5, 10, 20, 10/5 AGC (mm/mV)
Input Impedance: 50 MO (10Hz)
Input noise: <12.5µ Vp-p
Baseline anti slip: automatic

Record Mode: Auto/Manual/Rhythmic
Electrode rhythm: single electrode or triple electrode selectable
Battery: included rechargeable Li-ion, 14.4V (400 ecg prints)
Printing: built-in thermal printer
Paper: Z-fold and roller (216/210mm height)
Printing speed: 5mm/s, 10mm/s, 12.5mm/s,25mm/s, 50mm/s
Dimensions: 420mm x 330mm x 120mm
Display : 800 x 600 Multicolor LCD
Internal memory : 200 Patients




code: LTD455W
